General Design Type		For use with Outboard Slip Yokes
Spline Major Diameter	D	1.562
Spline Count		24.000
Spline Type		23 Based On 24 Spline
Bearing Diameter	C	1.575
Tube Diameter and Wall Size		3.500 X .083
End of Spline to Bearing Shoulder	Y	8.750
End of Spline to Point of Weld	K	9.875
Length of Spline	L	3.000
Thread Size
Shoulder Diameter	B	1.812
Length of Shoulder	G	0.880
Notes		Use boot 212007X, order separate

Midship Splines
Spline	1.562x23/24
C - Bearing	1.575
Tube	3.500 x .083
(Y)	8.750
(K)	9.875
(L)	3.000
(B)	1.812
(G)	0.880
Style	2
